SKY Agriculture DX20

Categories: , Product ID: 23091


 NEW DX20 Spreaders in stock.
Prices Starting From £4,600 + VAT with Hopper Cover & Road Lighting

Number 1 in spreading widths

Developed on the DPX range and perfected on the DX range, the width control of Sky spreaders is the benchmark in centrifugal spreading. It acts by modifying the drop point of the fertilizer on the disc using an exclusive outlet chute.

1. The chute: inclined, it accompanies the fertilizer precisely on the tray.

2. the drop point: this is the simplest device for adjusting the working width. Its adjustment does not require any modification of the rotation speed of the plates or touching the ejection blades.

spreading width adjustment

Graduated sectors redesigned for your comfort

2 strong arguments:

Large sectors for width and flow adjustments without risk of error,Total visibility of the graduations whatever the number of hectares spread.

flow and drain dx20

Flow test and drain: finally enjoy the easy things

Once the chute is in place, all you have to do is measure the distance indicated on the ruler and then weigh the result obtained. This same ruler will then give you the correct trap setting.

3 strong arguments:

Maximum accessibility,Quick assembly chute… without key,No restrictive handling.

DX / DX+ 2D

Fertilize your borders instantly without getting off the tractor!

100% electric

Electric control from the cabin without getting off the tractorNo hydraulic distributorZero broken grain

Still in the logic of modifying the drop pointNo alteration of your fertilizer

dx20 hopper bottom

Stainless steel double cone hopper bottom

The double-cone hopper bottom allows immediate detection of a flow irregularity linked to the presence of a foreign body.

In addition, its strongly inclined walls guarantee a very regular flow of fertilizer even on slopes and at the end of the hopper.

Working width 9-18m 9-18m
Levelled hopper capacity 900 l 1500 l
Overall width 2.29 m 2.29 m
Loading dimensions 1.23 x 2.21 m 1.23 x 2.21 m
Loading height 0.91m 1.12m
Weight (indicative) 300kg 340 kg
Payload 1,500 kg 1,500 kg
